hydraulic rock splitter for breaking rocks

Hydraulic rock splitter is used for rocks breaking.It can be electric driven or gasoline driven,pneumatic driven and diesel driven.

Suitable for different hole diameters.

Model 型号	Pistion diameter 活塞直径	Hole diameter request 钻孔直径	Hole depth 钻空深度	Wedge length 锲块长度	Splistting distance 裂缝宽度	Cracking time 劈裂时间	Expanding force in theoretically 理论劈裂力	The fact expanding fore 实际劈裂力	Single weight 单机重量
	mm	mm	mm	mm	mm	s	t	t	kg
MW38A	80	φ38-42	≥300	150-450	10-35	5~12	480-625	260-320	23
MW38b	80	φ38-42	≥500	150-450	10-40	5~12	500-650	265-360	26
MW42A	90	φ42-46	≥300	150-450	10-40	5~12	580-725	290-430	30
MW42B	90	φ42-46	≥500	150-450	10-40	5~12	600-800	310-520	33
MW44A	100	φ44-48	≥300	150-450	10-40	5~12	700-925	360-560	33
MW44B	105	φ44-48	≥500	150-450	10-40	5~12	750-975	380-620	35
MW46	110	φ46-50	≥500	150-450	10-40	5~12	800-1090	420-700	36
